fischer Meister-Box DuoPower / DuoTec + Screws

Name: fischer Meister-Box DuoPower / DuoTec + Screws
Brand: fischer

Produktne variante

Download of image data

Top Features

Transparent cover: Overview at a glance.
High quality assembly box for refilling.
No searching: most important diameters are pre-sorted.

The Duo of power and intelligence - The assortment for all building materials.

Advantages

DuoPower

Two material components for optimum load values and intelligent functions depending on the substrate.
Best possible feedback (feel-good factor) of the plug. You can feel when the plug is perfectly seated.
The narrow edge of the plug prevents it from slipping into the drill hole.
The pronounced anti-rotation lock prevents the plug from turning.

DuoTec

Flexible screw holder allows the use of screws and hooks with different thread forms.
Glass fibre reinforced plastics and the metal skeleton insert (fischer DuoTec 12) ensure the absorption of high tensile and shear loads in all panel building materials.
Soft, grey nylon support side distributes the load on the panel surface and thus minimises the weakening of the load-bearing building material.
Standard drill hole diameters and short tilting element for easy installation in narrow, even insulated cavities.
White collar sleeve with snap-in function enables quick and secure pre-assembly of the plug in the drill hole.
With scale on the tension band (fischer DuoTec 12) to determine the required screw length (scale value + 20 mm).

The fischer Meister-Box, made from a high-quality and impact-resistant plastic, is ideal for workshop and construction site and offers an optimum price/performance ratio. The practical installation box contains a selected assortment of plugs, screws and hooks for the most frequent applications and building materials. The interaction of the ideally matched components always guarantees the choice of a secure fixing solution. Thanks to the transparent lid and the compartments, the contents can be viewed at a glance. This saves time and guarantees that the suitable fixing element is selected. The fischer Meister-Box can be reused.

Applications

TV consoles
Lighting
Shelves
Light mirror cabinets
Letter boxes
Pictures
Fixing blinds
Curtain rails
Wash basin fixings
Plumbing and heating fixings
Bath and toilet installations
Range hood
Shelves
Wardrobes
Handles
Mirrors
Lamps
Heavy hanging baskets

Building materials

Concrete
Solid brick
Solid sand-lime brick
Aerated concrete
Vertically perforated brick
Perforated sand-lime brick
Plasterboard
Hollow blocks made from lightweight concrete
Cavity floor slabs made from bricks and concrete or similar
Natural stone
Solid panel made from gypsum
Solid brick made from lightweight concrete
Wooden panels, such as OSB boards, chipboard, MDF sheets
Steel plates
Plastic boards
Hollow blocks made from concrete

Podroben opis najdete v priloženem dokumentu

Functionality

DuoPower

The grey component made of high-quality nylon automatically activates the optimum functional principle (spreading, folding) for the best hold, depending on the building material.
The expansion wings of the red component support secure expansion and offer additional safety to the grey component.
The smooth-running opening ensures easy positioning of the screw and secure guidance and fixing in the screw channel.
The required screw length is calculated from the plug length + thickness of the mounting part + 1 x screw diameter.
For panel building materials, the unthreaded part of the screw must not be longer than the attachment part.

DuoTec

The fischer DuoTec is suitable for pre-assembly.
Simple installation using standard 10 or 12 mm drill bits.
The short tilting element makes it suitable for narrow cavities, even those insulated with mineral wool. Please note the length of the tilting element!
In solid building materials, such as concrete or wood, it works like an expansion plug. Attention, not with metric screws!
The flexible screw holder allows the use of wood, chipboard and metric screws and hooks.

Contents	30 x DuoPower 6 x 30 15 x DuoPower 8 x 40 10 x Countersunk head screw 5.0 x 55 6 x DuoTec 10 6 x Pan head screw 5.0 x 60
Packaging	Assortment box
Amount	87 pcs
GTIN (EAN-Code)	4048962276701
